Lifecycle

Obsolete Date 30-04-2027
End of support date 30-06-2028

Specifications

Interface SAS
Workload Read Intensive
Drive form factor SFF
Carrier type Basic Carrier
Capacity 7.68 TB
Write IOPS Random Write IOPS (4KiB, Q=16)=36,000 Max Random Write IOPS (4KiB)=37,000@Q4
Read IOPS Random Read IOPS (4KiB, Q=16)=98,000 Max Random Read IOPS (4KiB)=155,000@Q32
Power (Watts) 7.68
Lifetime writes 14,000
Plug type Hot Pluggable
Platform supported HPE Compute Mainstream Platforms, see QuickSpecs for more information
Warranty HPE Solid State Drives and Add-In Cards have a standard 3/0/0 warranty; Customer Self Repair (CSR) subject to maximum usage limitations. Maximum usage limit is the maximum amount of data that can be written to the drive. Drives that have reached this limit will not be eligible for warranty coverage.
Endurance DWPD (Drive Writes Per Day) 1
Height 15 mm

Quickspecs

Overview

Do you need to accelerate the performance of your read intensive applications? HPE Value SAS Read Intensive (RI) SSDs optimize your enterprise with faster 12 Gb data transfer rates and near price parity compared to enterprise 6 Gb SATA SSDs. HPE Value SAS RI SSDs deliver enterprise features at an affordable price for applications requiring high random read IOPS performance, and are ideal for read caching, social media and web servers workloads. HPE Value SAS RI SSDs transfer data at 12 Gb full duplex (bidirectional) allowing greater I/O bandwidth to alleviate bottlenecks at twice the 6 Gb interface of SATA SSDs. A single-ported version of enterprise 12 Gb SAS, HPE Value SAS RI SSDs provide slightly reduced performance in exchange for being price competitive to 6 Gb SATA SSDs. HPE Value SAS RI SSDs are presented as an HPE Multi Vendor SKU offering which provides customers with the shortest lead time to available supply on preferably priced HPE Value SAS RI SSDs.

What's new

Offering 960 GB, 1.92 TB, 3.84 TB, and 7.68 TB storage capacities on selected models of Value SAS SSDs.

Features

Assurance that the HPE Value SAS Solid State Drives selected delivers the minimum performance published or better.

Preferable pricing on HPE qualified Value SAS SSDs and extended SKU lifecycles simplifies the procurement process.

HPE Multi Vendor Offering for Value SAS SSDs Help Simplify Purchasing Decisions While Improving TCO

HPE Multi Vendor offering provides shorter lead times to best available HPE Value SAS SSD supply.

By improving performance at similar price points, HPE Value SAS SSDs deliver better data analytics performance per dollar than 6 Gb SATA SSDs.

HPE Value SAS Solid State Drives support full-duplex 12 Gb, versus SATA SSDs that are bottlenecked by 6 Gb SATA interface specification.

Featuring similar price points to 6 Gb SATA SSDs while delivering more performance per dollar compare to enterprise SATA SSDs in server applications.

HPE Value SAS SSDs offer a significant random IOPS performance boost over 6 Gb SATA SSDs.

HPE Value SAS Solid State Drives offer faster connection rates that can improve the performance of decision support system applications than SATA SSDs.

Value SAS SSDs Run More Data Analytic Workloads in Less Time and with Lower Latency than SATA SSDs

HPE Value SAS SSDs save time executing data analytic workloads with lower read latency needed to access and pull data compared to 6 Gb SATA SSDs.

Value SAS SSDs Deliver Twice the Interface Speed of SATA SSDs at a Lower Cost than SAS SSDs
