ARUBA NETWORKS

HPE Aruba Networking AP-565 (RW) 802.11ax Dual 2x2 Radio Integrated Omni Antennas Outdoor AP

Name: HPE Aruba Networking AP-565 (RW) 802.11ax Dual 2x2 Radio Integrated Omni Antennas Outdoor AP
Brand: ARUBA NETWORKS
SKU: R4W43A
Price: 4930.99 RON
Availability: OutOfStock

Cod: R4W43AEAN: 190017447346

Aruba AP-565 (RW) Outdoor 11ax AP

4.930,99 RON

TVA inclus

Stoc epuizat

Livrare expres prin FAN Courier sau GLS

Drept de retur în 14 zile calendaristice

Garanție: 60 luni (pers. fizice) · 12 luni (pers. juridice)

Lifecycle

Obsolete Date 31-12-2099
End of support date 31-12-2104

Specifications

Max bandwidths and peak data rate per band 20/40 (2.4GHz), 20/40/80 (5GHz), peak data rate 1.49 Gbps, maximum data rate 1.78 Gbps
Ultra tri-band (UTB) filtering No
Wi-Fi generation Wi-Fi 6 (802.11ax)
Wi-Fi radios Dual 2x2
Wired network interface 1 x 1GbE
AP management On-premises; Public Cloud; Virtual Private Cloud (VPC); as a Service
AP operating system support HPE Aruba Networking Wireless Operating System 8 and HPE Aruba Networking Instant OS 8.7.1.0 HPE Aruba Networking Wireless Operating System 10.3.0.0
Cellular support No
Deployment Outdoor
Integrated sensor No
IoT support IEEE 802.15.4/Zigbee or Bluetooth 5
Location services 802.11 FTM support
MACsec support No
Radio configuration options 2.4 GHz and 5 GHz
Regulatory FCC/ISED CE Marked RED Directive 2014/53/EU EMC Directive 2014/30/EU Low Voltage Directive 2014/35/EU IEC/EN/UL 62368-1 EN 60601-1-1, EN60601-1-2 Railway Certs: EN 50155:2017—Railway Applications EN 50121-1:2017—Railway EMC EN 50121-3-2—Railway EMC EN 50121-4:2016—Railway Immunity IEC 61373 ed2:2008—Railway Shock and Vibration For more country-specific regulatory information and approvals, contact your HPE representative.
Certifications CB Scheme Safety, cTUVus UL2043 plenum rating Wi-Fi Alliance® certified 802.11a/b/g/n/ Wi-Fi Alliance certified Wi-Fi 6 (802.11ax) Wi-Fi CERTIFIED® ac (with wave 2 features) Wi-Fi CERTIFIED Location
Warranty Limited lifetime warranty. See the warranty duration.
Shipping dimensions 6.5 X 6.5 X 5.1 in
Shipping dimensions 165 x 165 x 130 mm
Wi-Fi antenna Built-in omnidirectional antennas with 5.4 dBi gain maximum, for 5 GHz antennas and 3.2 dBi gain maximum for 2.4 GHz antennas
Ports E0: 10/100/1000BASE-T (RJ-45) USB-C console interface

Quickspecs

Overview

The HPE Aruba Networking 560 Series Outdoor Access Points provide cost-effective Wi-Fi 6 wireless connectivity in outdoor and environmentally challenging locations. With Wi-Fi 6 capabilities, Bluetooth 5 and 802.15.4/Zigbee radios, and maximum aggregate data rate of 1.49 Gbps, the 560 series delivers the speed and reliability needed to bring medium-density Wi-Fi 6 outdoors. These Wi-Fi 6 outdoor access points are ready to survive high wind, extreme temperatures, and moisture and can be quickly deployed using zero touch provisioning (ZTP). HPE Aruba Networking Central provides a single pane of glass for overseeing wired and wireless LANs, WANs, and virtual private networks (VPNs). AI‑powered analytics, end‑to‑end orchestration and automation, and advanced security features are built natively into the solution. The 560 series outdoor APs include a limited lifetime warranty.

What's new

Entry-level outdoor Wi-Fi 6 (802.11ax) access points that provide up to 1.49 Gbps peak aggregate data rate and are ideal for outdoor and warehouse environments
Purpose-built to survive in the harshest outdoor environments and extreme temperatures (-40˚C to +55˚C)
Ready for Internet of Things (IoT) with a built-in Bluetooth 5 and 802.15.4 radio that supports Zigbee
Small form factor for flexible deployment.
Client and RF optimization to match clients with the best available access point and reduce coverage gaps
Dynamic segmentation and policy enforcement firewalls (PEFs) that automatically enforce consistent policies across all networks, keeping users and devices secure

Features

Enhanced wireless experience with HPE Aruba Networking ClientMatch technology removes sticky client issues by steering a client to the AP where it receives one of the best radio signals.

It supports features such as orthogonal frequency-division multiple access (OFDMA), downlink MIMO (MU-MIMO), and target wait time (TWT).

For enhanced device assurance, the access points include an installed trusted platform module (TPM).

HPE Aruba Networking Central Client Insights uses deep packet inspection to provide additional context and behavioral information that help verify devices are receiving proper policy enforcement and continuously monitor for rogue devices.

HPE Aruba Networking 560 Series Outdoor Access Points are ideal for environmentally challenging locations and can endure extreme temperatures, persistent moisture, precipitation, airborne contaminants, dust, salt sprays, and maximum 165 mph wind speeds.

Weatherproof and temperature hardened, this series can handle temperatures ranging from -40˚C to +55˚C, including full solar loading.

With peak aggregate data rate of 1.49 Gbps (HE80/HE20), the series delivers the speed and reliability needed for most environments

Entry-level Outdoor Wi-Fi 6 Simple Access With Enhanced Security

Target wake time (TWT) improves battery life of IoT devices.

The AP supports Bluetooth 5 and Zigbee wireless protocols through an integrated IoT radio.

HPE Aruba Networking 560 Series Outdoor Access Points can serve as IoT platforms that bolster network security and provide coverage for a range of IoT devices without the need for network overlays.

IoT Ready

The AP simplifies policy enforcement by using the policy enforcement firewall to encapsulate all traffic from the AP to the gateway (or mobility controller) for end-to-end encryption and inspection.

It offers stronger encryption and authentication with WPA3, protected credentials/keys storage for guest access with Enhanced Open (OWE), and user and IoT access policy enforcement firewalls.

The HPE Aruba Networking 560 Series Outdoor Access Points offer enhanced security with dynamic segmentation to remove the time-consuming and error-prone task of managing complex and static VLANs, ACLs, and subnets by dynamically assigning policies and keeping traffic protected and separated.
