Mechanical Hardware PoE LEDs Dimensions 210.4 x 95 x 29 mm (8.28 x 3.74 x 1.14") Weight 610 g (1.34 lb) Enclosure material Polycarbonate Total non-blocking throughput 9 Gbps Switching capacity 18 Gbps Forwarding rate 13.392 Mpps Networking interface (8) 10/100/1000 MbE RJ45 ports (1) 1G SFP port

Mechanical Hardware PoE LEDs Dimensions 210.4 x 95 x 29 mm (8.28 x 3.74 x 1.14") Weight 610 g (1.34 lb) Enclosure material Polycarbonate Total non-blocking throughput 9 Gbps Switching capacity 18 Gbps Forwarding rate 13.392 Mpps Networking interface (8) 10/100/1000 MbE RJ45 ports (1) 1G SFP port Managementinterface Ethernetin-band Bluetooth BLE Power method External AC/DC adapter Power supply 27VDC, 4.4A power adapter (included) Supported voltage range 24 - 28VDC Max. power consumption 8W (excludes PoE output) ESD/EMP protection Air: ± 15 kV, contact: ± 8 kV Operating temperature -10 to 50° C (14 to 122° F) Operating humidity 5 to 95% non-condensing Certications CE, FCC, IC PoE interface (8) 27V passive PoE: 2-pair (pins 4, 5+/7, 8-) or 4-pair (pins 1, 2, 4, 5+/3, 6, 7, 8-) Max. Passive PoE wattage per port 30W/27VDC Passive PoE voltage range 27VDC System Status RJ45 data ports PoE Speed/link/activity SFP data ports Link/activity
